• Premium 2d & 3d – floor plans
• Luxury 3d elevation designs of all views
• Design development – a maximum of 40 drawing revisions
• Internal isometric views all rooms, open areas etc & detailed renders for each segment of the home for better understanding of the design
• Detailed landscaping design
• 3d walkthrough of the home along with internal & external walkthrough
• Hands on isometric 3d model of the home with separate floors
• Site survey by surveyor with instruments & drawing on the basis of survey

VR for the 3d walkthrough of the home along with internal & external walkthrough including interior renders

• Floor to floor height – 11’
• Steel (500 TMT bars) – JSW/SAIL/Vizag
• Cement (Grade 53) – ACC/ Ultratech
• UG Sump built with RCC & waterproof plastered as per capita requirment
• Concrete – M25 grade
• Machine cut solid Block walls – 8” & 4” thickness of APCO/ Sonika/ equivalent
• Internal, external and toilet wall – column joints plastering with chicken mesh using double washed M sand
• Internal, external and toilet wall – column joints plastering with chicken mesh

Waterproofing compound – Dr.Fixit/FOSROC for external walls Crystalline waterproofing, Cinder filling in sunken toilets, Heat & Waterproofing in Terrace Steel/concrete lofts – Not Included Ledge wall for incorporating concealed sanitary parts is included

• Working drawing for all works
• Schedule of Openings
• Section and Elevation
• Detailed portfolio of the home post-handover

• Complete 3D design interiors, only if executed by KITOV
• 2D furniture layout.

Assisting in interior procurement

• Structural Design as per IS Code.
• Good for construction drawings
• Soil Test Report
• Overlapped Structural, Architectural & MEP Drawings
• 3D structural drawings & Design Analysis Report

• Electrical Layout
• Plumbing Water Line Layout
• Plumbing Drainage Line Layout
• Detailed HVAC design

Owners will provide liaison assistance with different government agencies, obtain permissions, licenses & sanction fee for the following (if applicable)

• Construction Plan Sanction
• Temporary Electricity connection
• Permanent electrical connection
• Water connection

Sewage connection

• Kitchen & Bedrooms – Vitrified Tiles – Rs.90/- per Sqft
• Main Living Room, Dining – Italian Marble/Premium Finished Vitrified tiles of 4’x8’ dimension -Rs.450/- per Sqft
• Staircase Area granite – Rs 150(Only granite)
• Balcony, Sit-out, Passage & other common Areas – Anti-skid tiles – Rs.70/- per Sqft
• Toilet Floor – Anti-skid tiles – Rs.75/- per Sqft
• Toilet Wall Dado (Full height) – Light & Highlighting tiles – Rs.70/- per Sqft
• Parking Area – Parking tiles/Designer Pavers – Rs.70/- per Sqft
• Kitchen counter top – Granite – Rs.165/- per Sqft
• Kitchen Wall Dado (Up to 2’ above counter) – Backsplash tiles – Rs.75/- per Sqft
• Puja Room- Wall tiling – Full height – Rs 65 per Sqft
• Puja Room- Granite slab- Rs-120/- per Sqft
• No limitation of tile size
• Tile grouting with spacer joint & with epoxy grout in bathrooms

Setback area tiles of 50 per sqft will be provided. (if setback area is charged)

• internal wall & ceiling: 3 coat wall putty + 1 coat primer coat + 2-3 coat premium emulsion paint
• External walls – primer coat + Apex weather proof paint

Brand – Asian/Berger/Dulux

• Legrand Lyncus/myrius (Touch screen switch provision only)
• A main DB & MCB – ABB/Schneider/Legrand make
• Provision for home automation is included
• AC provisions – in all rooms, living and dining
• Electric Car charging point – Parking area
• CCTV provision

• Water supply system – Internal & External Connection for water inlet from corporation.
• Separate bore well & corporation lines, if needed for Kitchens. If separate tank is needed, shall be charged on actuals
• External sewage system – Inspection chambers & sewage outlet to site boundary
• Class B CPVC pipes – Ashirwad/Astral make
• Solar & Geyser Provision
• Rain water harvesting facility – Ground water recharge
• PVC Overhead Tank based on per capita consumption from Sintex

• FRP Chamber covers shall be provided for IC
• Separate sewage & drainage lines

Separate hot & cold-water lines for sink

• Kitchen sink & Accessories: SS/Granite/Carysil – Rs.22,000/- per kitchen
• CP & Sanitary fixtures such as Wash Basin, WC, Taps and other accessories like bottle trap, gratings etc. : Jaquar/Hindware – Rs.40,000/- per bathroom attached toilet and Rs.15,000/- per  powder room

• Main, Puja Door – Teak Wood frame & shutter including hardware – Rs.60,000/- per door
• Internal Door – Sal wood frame & flush shutter including hardware – Rs.12,000/- per door
• Internal door frames & shutter – Painted/Hand Polished
• Main, Puja Door – Polished with PU finish spray
• Bathroom Door – Frame & shutter including hardware – Rs.10,000/- per door
• Door Hardware – Ozone/Europa/Dorma make
• Door Hinges – SS hinges

Door & Door Frame cost – Inclusive of planning, rebate, transportation etc.

• UPVC windows – 5mm clear glass with MS Grills
• OR

Basic price: uPVC with MS grill or wooden including hardware – Rs.770/- per Sqft OR Wooden windows –  Sal wood  Frame (5”x3”)  &  Honne Shutter (1.5”  thickness) with clear glass and grill rods

• Main Gate: Designer Gate with Shera boards – Rs. 450/- per Sqft
• External staircase & balcony railing: MS Railing – Rs. 660/- per Rft
• Internal staircase railing: SS Railing – Rs.1080/- per Rft
• Utility grill is not included in the package

Waterproofing is included for Utility & balcony portions

• Compound wall – Solid block walls of 4” thickness to suit the elevation (If charged)
• Excavation, Foundation, PCC, Size Stone Masonry with DPC course above SSM
• Height of Compound wall– 5 Ft above Plinth level

Compound wall – Plastered & Painted

• This proposal includes a luxurious elevation

A 3D elevation is presented for client to choose from & design further

• A design if needed to be modified more than thrice shall be charged for accordingly
• Government fees for the liaison bodies to be paid directly by the client
• The complete fee payment for plan sanction in Panchayat limits need to be borne by client

• Assuming the site & road level to be equal, if the ground level needs to be raised above 18”, it shall be charged for accordingly
• Hard rock/soft rock excavation, if it arises shall be charged for accordingly
• Buying new earth/sending existing earth for excavation/backfilling purpose shall be charged on actual
• There is no basic price/ cap of steel or cement. However, in case there is huge fluctuation of over 45% of the average market price during the signing of the agreement the difference shall be charged in consultation with the client
• Any work not mentioned within this package or outside the site boundary shall be charged for accordingly
• Percentage of openings for doors & windows – 29% Maximum
• One point of electricity & water needs to be provided by the client free of cost to facilitate construction
• SBC of soil is considered at 180 KN/M2 and depth of the foundation considered at 5 Feet, any increase in depth shall be charged accordingly on actuals upon site conditions
• If there is constraints in material delivery or socking place and materials to be order in small quantities, the additional charges for the same shall be charged on actuals
• A specific area to construct labour and material shed needs to be provided within 50 feet from the construction place by the client
• Any road cutting charges for the connection of Electricity and Sewage lines is not included, such works shall be charged additionally
• Site related small costs like tarpaulin, temporary wiring within the site & etc, are included and no additional cost

NOTE: The above-mentioned material specifications are generalized, the inclusion or the exclusion of the same shall vary depending on the floor plan.

Municipal Approval

Borewell

Electricity Connection

Sewage & Sewerage Connection

Compound Wall

Elevation Treatment (Nominal Elevation Shall Be Provided

Seller has the right to modify the design of his standard buildings and to the substitute material equal to of superior to that

originally specified (in order to permit incorporation of changes and improvements, in the continued development of the Seller’s

product).

Agreement and orders CANNOT be cancelled or modified by Buyer under any circumstances without Buyer first reaching an agreement in writing with Seller covering all damages. If cancellation or modification is agreed by Seller, Buyer agrees to promptly

pay all reasonable engineering and other expenses incurred by Seller in connection with this Agreement and in any case not less

than 5% of the Agreement price in case of cancellation.

A customized payment schedule will be shared based on the project specifications.

• Construction guarantee – 1 Year; Waterproofing warranty – 10 Years
• Guarantee & warranty is provided on Stamp paper
